Features:
1. With multi-coil technology, the rebar position can be located more real-time and accurately;
2.Rebar position, spacing and cover thickness are displayed on the same screen
3. USB data transmission
4.Up to 65m for profile and grid scan modes and up to 10m for signal scan mode;
5.Two data view modes: graph and list, which enables convenient and flexible operation as well as quick view of the data;
6.Bluetooth data transmission
7.Five scan modes are provided to suit for different measuring environment
Specification
| Applicable range | Φ6mm~Φ50mm | Maximum
allowed error |
±1 rebar standard
|
|
| Protective layer thickness
|
First range | Second range | Communication interface
|
USB
Bluetooth |
| 1~80 | 1~180 | Power | Built-in chargeable lithium
battery |
|
| Maximum
allowed error for protective layer thickness |
±1 mm | 1~59 | Battery Time | >10 hrs |
| ±2 mm | 50~69 | Data logger | Up to 3584 objects | |
| ±4 mm | 70~98 | Operating mode | Film button | |
