Main features
Multiple range options; digital pressure display; zero
point and range adjustment are convenient; reverse polarity
protection and current limiting protection; anti-lightning and
impact; intrinsically safe and explosion-proof; , high
reliability;
Technical performance
Range selection : 0~1m. . . 100m
Output signal: 4-20mA
Power supply voltage: 8 ~ 30VDC
Accuracy grade: 0.25%,0.25%
Allowable overload: 150% of standard range
Operating temperature: -40°C ~ 80°C (special order)
Long-term stability: ≤±0.2%FS/year
Protection class: IP65
Seal material: Nitrile rubber Fluorocarbon rubber
Pressure port: 1Cr18Ni9Ti
Housing material: Die-cast aluminum
Sensor diaphragm: stainless steel 316L
